LM microscope adapters for DSLR or system cameras with integrated optical filters

Configuration flexibility and a high level of image quality are essential prerequisites when it comes to scientific imaging. The modular design and premium quality of our LM adapter systems make them ideally equipped to meet these requirements.

LM adapter polarisation imaging without special microscope
Demo photo: polarisation imaging without special microscope

LM microscope adapters offer the option to add a filter to the adapter. This permits the use of optical filters (such as polarisation filters, grey filters, UV filters, IR filters, etc.) independently of the type of microscope being used, which means that even very basic and affordably priced microscopes can be employed for special imaging applications.

The filter (a polarisation filter, for example) is inserted at the level of the bayonet mount. This does not change the height of the adapter.

LM microscope adapter for digital system cameras with polarisation filter added to the adapter:

microphotography, photomicrography, polarisation filter in adapter solution, DSLR adapter, microscope adapter

Shown in the image below: LM microscope adapter attached to a digital system camera (Nikon Z7):

DSLM with adapter polarisation filter

Demo photo: adhesive tape dispenser roll with tape, taken with Nikon Z7 system camera attached to a stereomicroscope using a LM microscope adapter with integrated polarisation filter

adhesive tape dispenser roll with tape, Nikon Z7 DSLM, LM adapter with integrated filter

02.09.2019

Photography

Fitting the microscope to digital single-lens reflex (DSLR), system or C-mount cameras is easy with our LM digital SLR adapters, which feature a plan achromatic optical system. Our products make it possible to capture top-quality microscope images. To help you select the adapter that is right for your camera, we have set up an online configurator on our website. You can also email us – ideally with attached photographs of your microscope.

Modern DSLR and system cameras offer the latest technology and are generally very well suited for microscopy applications. Most of them can be controlled remotely via PC/Mac. Because of their high sales volumes, they offer an excellent price/performance ratio compared to special-purpose microscope cameras.

Features of top DSLR and system cameras:
- Large, powerful full-frame sensors (36 x 24 mm)
- Sensor resolution of 50 megapixels
- High light sensitivity (ISO 100,000+)
- Extensive dynamic range (up to 14 aperture stops/f-stops)
- Short exposure times (1/8000 second):
- Full/Ultra HD (4k) video function
- Live video capture on external monitors in ultra HD quality

In most cases, these cameras are significantly more powerful than microscope cameras with smaller sensors (1/2" or 2/3"). On our website you will find our current camera recommendations and a camera ranking which is specifically tailored to microscopy applications.


New LM Digital Adapter for: Sony Alpha 9 II (ILCE-9M2) / Sony Alpha 9 / Canon EOS R with Canon Adapter EF-EOS R / Canon EOS Ra (Astro) with Canon Adapter EF-EOS R / Sony Alpha 7R IV / Canon EOS RP with Canon Adapter EF-EOS R / Sony Alpha 7S II / Sony Alpha 7R III / Nikon Z6 with F-Mount Adapter FTZ / Sony Alpha 7R II / Nikon Z7 with F-Mount Adapter FTZ / Sony Alpha 7S / Nikon Z50 with F-Mount Adapter FTZ / Nikon D850 / Canon EOS 1D X Mark II / Sony Alpha 7III / Nikon D5 / Sony Alpha 6600 / Sony Alpha 6400 / Sony Alpha 6100 / Canon EOS 1D X / Nikon D4s / Olympus OM-D E-M5 III / Canon EOS 90D / Canon EOS 5D Mark IV / Nikon D4 / Nikon D750 / Canon EOS 6D Mark II / Sony Alpha 6300 / Sony Alpha 6500 / Nikon D500 / Nikon D810 / Nikon D800 / Nikon D800E / Nikon Df / Panasonic Lumix DC-G9 / Nikon D610 / Nikon D600 / Canon EOS 250D / Canon EOS M50 / Canon EOS 6D / Sony Alpha 99 II (SLT-A99 II) / Canon EOS 5DS R ( without low-pass filter) / Olympus OM-D E-M1 Mark II / Canon EOS 80D / Canon EOS 5DS / Sony Alpha 77 II / Canon EOS 70D / Nikon D7200 / Pentax K-1 Mark II / Canon EOS 200D /
